CH Precision展出全新旗舰M1后级

smalltiger

小虎覺得CH Precision 是近年來叫好又叫座的一個瑞士品牌,他的D1 SACD player口碑極好,而C1 D/A converter+前級又令品牌更上一層樓, 丞接A1 stereo power amp後, 不久又在2014 CES推出M1 頂級stereo power amps, 令產品系列完成大業.




sourced from 21HiFi website
CH Precision展出全新旗舰M1后级，集合了顶级音频技术和最新科技于一身，采用双单声道的设计，全平衡放大技术，装载2000VA变压器和每声道100,000uF电容滤波（一台M1装载20万uF），提供强大的电源供应。前面板设有一个OLED显示屏，用家可以更详细了解功放的工作状态。。M1后级具有4种输出模式选择，包括立体声模式、Active/Bi-amp、Passive/Bi-amp和Bridge桥接单声道输出，在立体声模式下8欧负载下提供200Wx2的输出，而在桥接模式下单声道输出700W。CH Precision M1可以设定总体负回授参数，可以独立调节每个通道的信号反馈和增益，提供有10％增益步进0.5dB可调，能更好地满足不同扬声器的搭配。在Bi-Amp模式下，M1后级可分别驱动同一声道的中高音与低音，其中中高音输出部份是工作于无负回授的模式，实现更干净通透的中高音，而低音输出则工作于适度增加负回授，能保证低音的驱动力。同时对应中高音与低音的效率不一样，可以自由调整输出增益修正。但CH Precision 全新旗舰M1后级对工作环境也是有要求的...建议配置专门的20A电源线路供电，在CES 2014上的演示，以LP为主要演示音源，奢华的音色、丰富的细节和"摸得着"的真实声音重现，实在是一台值得期待的超级功放。CH Precision现场没有公布M1的价钱，定位于顶级市场。

馬丁

小虎哥係米有咩大動作.post貢多正嘢上來

Dee

小虎哥係米有咩大動作.post貢多正嘢上來

kelvinhin

好靚仔, 好正, 期待它的表現!

smalltiger

馬丁 發表於 2014-1-17 17:42
小虎哥係米有咩大動作.post貢多正嘢上來

冇呀，分享吓D好野，器材不追了，主力都是買番d CD算了。

pl96

smalltiger 發表於 2014-1-17 19:59
冇呀，分享吓D好野，器材不追了，主力都是買番d CD算了。

係咪過完年就入手

smalltiger

pl96 發表於 2014-1-17 20:14
係咪過完年就入手

小虎禾冇錢，哈哈哈。

ma73

好介紹

Pandaking

When will CH Precision come out with Preamp??

smalltiger

Pandaking 發表於 2014-1-18 22:22
When will CH Precision come out with Preamp??

C1might be seen as a pre-amp with built-in D/A converter.

CKKeung

The leading-edge technological advancements implemented on the A1 were further refined, among others is the ExactBias circuitry and a finer loudspeaker matching.
Specified at 200W RMS into 8Ω in monaural mode, 2x 200W RMS into 8Ω in bi-amplification mode and 700W RMS into 8Ω in bridge mode.
The M1 houses a dedicated 2200VA power transformer.

Modularity
• Monaural mode
• Bi-amplification mode
• Bridge mode

Power Supply
• Dedicated 2200VA power transformer mounted on silentblocks for minimal vibration transmission
• Magnetically and electrostatically shielded transformers
• Hyper fast soft recovery diode bridge rectifier
• 4-pole 100’000uF reservoir and filtering capacitors
• Dedicated 20A mains socket for audio power section

Full Analog Signal Path
• Pure class A, fully symmetrical design
• Fully discrete, ultra low noise, high slew rate design
• No capacitor in the audio signal path
• No output relay
• Argento loudspeaker binding posts and internal wiring

Gain Trimming
• Trim gain to accommodate loudspeaker sensitivity
• 24dB range in 0.5dB steps

Global Versus Local Feedback Ratio
• Ranging from 0% – local feedback only – to 100% – global feedback only – in 10% steps
• Feedback can be set on the fly from the user interface
• Independent feedback ratio in bi-amplification mode

Output Stage ExactBias
• Amplifier output stage and listening room temperature independent bias
• Patent-pending ExactBias regulation circuitry

Protections

• Non-invasive output stage voltage, current and temperature monitoring
• Protection procedures in case of output short circuit, open connection or excessive temperature
• Instantaneous output power and temperature can be displayed on the front panel


smalltiger

CKKeung 發表於 2014-6-28 07:22
The leading-edge technological advancements implemented on the A1 were further refined, among others ...

Thanks CK hing  for good sharing and enriching information of CH M1 mono block amps

AS881

但點解佢地部部機都一樣樣
