McIntosh MX121 AV Control Center

bigpun1975

MX121 是最優秀的家庭影院系統的控制中心。所有當前和舊式的音訊和視頻的來源都能夠處理和通過 MX121 操作。廣泛和靈活的功能設置，允許基於 MX121 的系統，以將配置為匹配使用者的確切需要。家用網路乙太網通信被支援，這樣，您可以直接從您的電腦和互聯網流音訊和照片。蘋果 AirPlay 允許從任何設備，以及數位 iPod 的 USB 輸入的後面板上的 itunes 音樂庫無線流 ®，iPad ®，或 iPhone ® 連接。




Features

Ultra Low Distortion (DSP Bypass)
0.005%

Channel Formats
Stereo, 5.1, 7.1, Two Mono Subwoofers

Balanced Input
1 set-Stereo

Balanced Outputs
7.1 + Second Subwoofer, or Height or Width

Unbalanced Inputs
7 Stereo + Moving Magnet Phono, 7.1 Input

Unbalanced Outputs
7.1 + SW, or H-2, or W-2, + VCR-2, + CDR-2

Digital Inputs
3-optical, 2-coax

Digital Output
1-optical

HDMI Inputs
6 - with 3D video pass-through, ARC, CEC, Deep Color, x.v.Color, Auto Lip Sync, Advanced HD audio

HDMI Outputs
One - Zone A, with or without ARC, 3D Video Pass-Through, CEC, Deep Color, x.v.Color, Auto Lip-sync

Component In and Out4 in and 2 out

Composite/S In and Out
5 in and 3 out

Additional Zone Outputs
Two Stereo: Zone 2- Analog audio/video, Zone 3-Analog audio

Max. # of audio channels in Zone A
8

DSP Room Correction
Audyssey MultEQ XT, Dynamic EQ / Dynamic Volume. DSX

Microphone and stand included
Yes

Advanced Connections
Ethernet Web interface, Update, IP-based control + Web Data Streaming

Network Features
DLNA 1.5 Certified, Pandora, Internet Radio, Flickr

Unique x-over Frequency, Each Speaker
Yes

Special Features
Rear Panel USB-Apple Doc, HDMI in standby, Apple AirPlay

Third Party Control
RS232, Web IP, Serial Data input, IR input port

Tone Controls
Nine Band Equalizer, Bass and Treble

OSD Overlay on HDMI output
Yes

Input-Output Format Indicators
9 in and 9 out

Control Of McIntosh Sources
Yes, by handheld MX121 remote, 1 Data Out, 2 Power Control Trigger jacks

Video Scaling
Yes, up to 1080P HDMI

Dolby Processing
True HD/Digital Plus&EX/Pro Logic IIz, IIx

DTS Processing
HD Master & High Res. Audio/ES/96/24, Discrete & Matrix6.1/Neo:6/Express/Neural

Pure Stereo DSP Bypass Mode
Yes

Weight
30 lbs (13.6kg) net, 54 lbs (24.5kg) shipping

Dimensions
17 1/2" (44.45cm) W x 7 5/8" (19.37cm) H x 19 1/2" (49.53cm) D

bigpun1975

呢部行,
Audyssey MultEQ XT

1o1o

哇。這 Model 貴到暈，我這窮人買唔起

bigpun1975

1o1o 發表於 2012-3-26 17:01
哇。這 Model 貴到暈，我這窮人買唔起

$ 6000建議零售價........美金??

ilccmcf

FH FW 只可以用RCA ......... 會唔會怪左D ???
好心做埋11.2 XLR 啦 !!!

1o1o

ilccmcf 發表於 2012-3-26 17:16
FH FW 只可以用RCA ......... 會唔會怪左D ???
好心做埋11.2 XLR 啦 !!!

係啊，放大相才看到，CHing 好眼力。
真是有點怪


- 發送自我的 iPhone 大板凳應用

qq1122yq

1o1o 發表於 2012-3-26 17:22
ilccmcf 發表於 2012-3-26 17:16
FH FW 只可以用RCA ......... 會唔會怪左D ???
好心做埋11.2 XLR 啦 !!!

因為佢春心動！

lamborghini436

bigpun1975 發表於 2012-3-26 17:06
$ 6000建議零售價........美金??

買左啦 ......................................................




































































































唔系我

ilccmcf

qq1122yq 發表於 2012-3-26 17:26
因為佢春心動！

近排玩黑膠多~~~ AV 野放下一排先 !!! 哈

ilccmcf

1o1o 發表於 2012-3-26 17:22
ilccmcf 發表於 2012-3-26 17:16
FH FW 只可以用RCA ......... 會唔會怪左D ???
好心做埋11.2 XLR 啦 !!!

初初以為新機只得7.2想鬧添呀~~~~ 但係又有DD IIz 先覺得怪..... 睇真d 原係RCA 有FW FH !!! CRAZY !!!

估估下咁

qq1122yq

ilccmcf 發表於 2012-3-26 17:39
近排玩黑膠多~~~ AV 野放下一排先 !!! 哈

真爽耶！

axgroup

xyzero

bigpun1975 發表於 2012-3-26 16:53
呢部行,
Audyssey MultEQ XT

可惜唔係行XT32

番薯

是否還有以前的 Room Correction 功能？

bigpun1975

番薯 發表於 2012-3-27 16:28
是否還有以前的 Room Correction 功能？

呢部唔係用room perfect 用audyssey

kachow

bigpun1975 發表於 2012-3-27 16:33
呢部唔係用room perfect 用audyssey

audyssey即係而家日本機用緊個d?

bigpun1975

kachow 發表於 2012-3-27 16:39
audyssey即係而家日本機用緊個d?

yes

kachow

bigpun1975 發表於 2012-3-27 16:41
yes

美國有人用緊..佢既初步comment係:

My MX-121 was set up yesterday. Some very quick impressions are below.
I'll be giving it a more thorough workout today, and over the next few days.

Some items to remember. Previous pre-amp was the MX120. It did not decode the HD audio formats on BR. My BR player (Denon 4010) did that.

* The HT is definitely better in two ways. First, the onboard HD audio decoding was noticeably nicer that the the BR decoding.

* Secondly, the Audyssey worked nicely in my room. Most notably, the bass integration is better. A very integrated sound is presented. More in the middle of the action.

* The Audyssey can be turned off. You can also choose Audyssey flat, or even bypass Front L/R. Several flavors.

* The internet radio and Pandora work very nicely.

* Airplay worked quite well. My installer whipped out his iPhone, I logged him into my NW, and we could select the MX-121. Still need to test that iTunes on a PC works.

Initial impression is that this is a pretty nice jump from the MX-120. A modern, full featured processor.


Hope this helps.

bigpun1975

kachow 發表於 2012-3-27 16:44
美國有人用緊..佢既初步comment係:

My MX-121 was set up yesterday. Some very quick impressions are  ...

buy la buy la

MarkMak

lamborghini436 發表於 2012-3-26 17:29
買左啦 ......................................................

有機會真想聽吓
